Low Backlash Lightweight Harmonic Reducer Gearbox

Product Description

Strain wave gear (also known as harmonic drive gear) is a type of mechanical gear system that uses a flexible spline with external teeth, which is deformed by a rotating elliptical plug to engage with the internal gear teeth of an outer spline. Outer circle: circular spline (fixed)

The core operation of Strain Wave/Harmonic Gearboxes hinges on the interaction between three primary components: the Wave Generator, Flexspline, and Circular Spline. Each plays a crucial role in converting input torque into precise output motion, setting these gearboxes apart in terms of efficiency and precision.

Harmonic Drive systems are useful in increasing the output torque in gears used in milling, in manufacturing, and in machines that use robotic arms.

Parameters Table

Detailed Images

	Key Attributes of LHT - I Model 40 Harmonic Gear Units
	Product	Model 40 Harmonic Drive
	Components	Wave Generator, Flexspline, Circular Spline
	Reduction Ratio	50:1, 80:1, 100:1, 120:1
	Backlash	Less than 20 Arc Sec
	Average Input Speed	4000 r/min
	Max Input Speed	3000 r/min
	Design Life	15000 hours
	Model	40
	Weight	4.4 kg
	Warranty	1 Year

Applications

Humanoid Robot	CNC Machines	Manufacturing Systems
