    Single Shaft Integrated Planetary Speed Reducer High Precision Gearbox

    Ask Lasest Price
    Brand Name : Giant Precision
    Model Number : NFR Series Planetary Gearboxes
    Certification : ISO9001
    Price : To Be Negotiated
    Payment Terms : T/T
    Supply Ability : 20000 Sets per Month
    Delivery Time : 3-4 Weeks
    • Product Details
    • Company Profile

    Single Shaft Integrated Planetary Speed Reducer High Precision Gearbox

    Single Shaft Integrated Planetary Speed Reducer High Precision GearboxSingle Shaft Integrated Planetary Speed Reducer High Precision Gearbox

    Specification Segment number Ratio NFR075 NFR100 NFR140 NFR180 NFR220 NFR250
    Rated output torque Nm single 3 130 220 330 890 1350 2380
    4 150 300 560 1100 2000 3050
    5 160 340 610 1180 2050 3200
    6 150 300 600 1100 1900 2850
    7 150 290 560 1000 1600 2850
    8 130 250 550 960 1550 2500
    10 110 220 460 950 1250 1850
    14 150 290 560 1000 1600 2850
    16 130 250 550 960 1550 2500
    20 110 220 460 950 1250 1850
    double 15 130 220 330 890 1350 2380
    16 150 300 560 1100 2000 3050
    20 150 300 560 1100 2000 3050
    25 160 340 610 1180 2050 3200
    30 150 300 600 1100 1900 2850
    35 150 300 560 1000 1700 2850
    40 130 250 560 950 1600 2750
    45 — — 460 — — —
    50 160 310 610 1180 2000 3100
    60 150 300 560 1050 1700 2850
    70 150 290 560 1000 1600 2800
    80 130 250 550 950 — —
    100 110 220 460 950 1250 1850
    120 150 300 600 1100 1900 2850
    140 150 290 560 1000 1600 2850
    160 130 250 550 960 1550 2500
    200 110 220 460 950 1250 1850
    Rotary inertia Kg.cm3 single 3 2.25 6.84 23.40 68.90 152.09 280.86
    4 2.25 6.84 23.40 68.90 152.09 280.86
    5 2.25 6.84 23.40 68.90 152.09 280.86
    6 2.25 6.84 23.40 68.90 152.09 280.86
    7 2.25 6.84 23.40 68.90 152.09 280.86
    8 2.25 6.84 23.40 68.90 152.09 280.86
    10 2.25 6.84 23.40 68.90 145.82 270.07
    14 1.87 6.25 21.80 65.60 145.82 270.07
    16 1.87 6.25 21.80 65.60 145.82 270.07
    20 1.87 6.25 21.80 65.60 145.82 270.07
    double 15 0.35 2.25 6.84 23.40 68.90 152.09
    16 0.35 2.25 6.84 23.40 68.90 152.09
    20 0.35 2.25 6.84 23.40 68.90 152.09
    25 0.35 2.25 6.84 23.40 68.90 152.09
    30 0.35 2.25 6.84 23.40 68.90 152.09
    35 0.35 2.25 6.84 23.40 68.90 152.09
    40 0.35 2.25 6.84 23.40 68.90 152.09
    45 — — 6.84 — — —
    50 0.35 2.25 6.84 23.40 68.90 152.09
    60 0.35 2.25 6.84 23.40 68.90 152.09
    70 0.35 2.25 6.84 23.40 68.90 152.09
    80 0.35 2.25 6.84 23.40 — —
    100 0.35 2.25 6.84 23.40 68.90 152.09
    120 0.31 1.87 6.25 21.80 65.60 145.82
    140 0.31 1.87 6.25 21.80 65.60 145.82
    160 0.31 1.87 6.25 21.80 65.60 145.82
    200 0.31 1.87 6.25 21.80 65.60 145.82

    Single Shaft Integrated Planetary Speed Reducer High Precision GearboxSingle Shaft Integrated Planetary Speed Reducer High Precision GearboxSingle Shaft Integrated Planetary Speed Reducer High Precision GearboxSingle Shaft Integrated Planetary Speed Reducer High Precision GearboxSingle Shaft Integrated Planetary Speed Reducer High Precision GearboxSingle Shaft Integrated Planetary Speed Reducer High Precision Gearbox

    Parameters Table Segment number Ratio NFR075 NFR100 NFR140 NFR180 NFR220 NFR250
    Max acceleration torque Nm 1,2 3~200 1.8 times rated output torque
    Emergency stop torque Nm 1,2 3~200 3 times rated output torque
    Rated input speed rmp 1 3~20 4000 4000 3000 3000 2000 1500
    2 15~200 4500 4000 3000 3000 2000 2500
    Max input speed rmp 1 3~20 8000 8000 6000 6000 4000 2500
    2 15~200 8000 8000 6000 6000 4000 4000
    Ultraprecise backlash arcmin 1 3~20 ≤2 ≤2 ≤2 ≤2 ≤2 ≤2
    2 15~200 ≤4 ≤4 ≤4 ≤4 ≤4 ≤4
    Precise backlash arcmin 1 3~20 ≤4 ≤4 ≤4 ≤4 ≤4 ≤4
    2 15~200 ≤7 ≤7 ≤7 ≤7 ≤7 ≤7
    Standard backlash arcmin 1 3~20 ≤6 ≤6 ≤6 ≤6 ≤6 ≤6
    2 15~200 ≤9 ≤9 ≤9 ≤9 ≤9 ≤9
    Orsional rigidity Nm/arcmin 1,2 3~200 14 31 57 182 400 580
    Max. radial Force N 1,2 3~200 4800 9450 15200 23000 34000 58000
    Max. axial Force N 1,2 3~200 3800 6250 12000 14500 23000 59000
    Tilting moment Nm 1,2 3~200 365 990 1900 2870 5550 8500
    Service Life hr 1,2 3~200 20000hr(continuous operation 10000hr)
    Efficiency % 1 3~20 ≥95%
    % 2 15~200 ≥92%
    Weight kg 1 3~20 6.4 13.9 23.7 50.0 83.0 100.3
    kg 2 15~200 7.8 15.1 26.7 54.0 95.0 125.3
    Operating Temperature ℃ 1,2 3~200 -10℃-90℃
    Lubrication 　 1,2 3~200 Synthetic grease
    Protection Class 　 1,2 3~200 IP65
    Mounting Position 　 1,2 3~200 Any direction
    Noise Level (N1=3000rpm,Non-Loaded) dB(A) 1 3~20 ≤65 ≤68 ≤70 ≤72 ≤74 ≤75
    2 15~200 ≤65 ≤68 ≤70 ≤72 ≤74 ≤75
